- UL Listed , FCC and CE Approved & RoHS
Compliant
- 17.1" ultra bright/contrast TFT screen
- Meets EIA-310C & IEC-3 specifications
- Heavy-duty steel
- Support DOS, Win 3.X, Win 95 / 98 / 98SE
/ 2000 / ME / XP, WinNT, SCO Uix, HP Unix, Linux, Netware
- 105-key with numeric keypad and built-in
touchpad keyboard
- 17.1" TFT 1280 x 1024
- Anti-glare tempered glass for added
protection to the LCD screen
- Built-in Power Adapter
- Auto Power Switch
- Built-in side railing for instant
installation
- Movable front panel offers additional
comfort during data entry
- Keyboard available in multiple languages
- Available in black and Customized colors
available
- Optional DC-48V power supply /
Touchscreen
- PS2 KVM cable connector : 15Pin D-sub
Male (to Cascade VGA port), PS/2 x2 Male (to Cascade PS/2 ports), 15Pin
D-sub Male (to Console VGA port), PS/2 x2 Male (to Console PS/2 ports)
|
|
I
|
II
|
III |
|
Model No
|
LCD1U17-03
|
LCD1U17-03-8KVM
|
LCD1U17-03-16KVM
|
|
Certification
|
UL Listed , FCC and CE Approved |
|
Ports switch for PC
|
Single port
|
8 ports
|
16 ports
|
|
Dimension
|
442.4 x44.5 x550mm /
17.0" x 1.7" x 21.7"
(W x H x D)
|
442.4 x 44.5 x 580mm /
17.0" x 1.7" x 22.8"
(W x H x D)
|
17.5" x 1.75" x 24.625" /
444.5mm x 44.5mm x 625.0mm
(W x H x D)
|
|
Power Supply
|
1U, AC 50W, DC +48V, 80W
auto switching
|
|
|
|
Extension Cable
|
none
|
3 IN 1
|
3 IN 1
|
|
Extension Rail
|
Up to 35.4" (900mm)
|
Up to 35.4" (900mm)
|
Up to 35.4" (900mm)
|
|
Chassis
|
Heavy-duty Steel
|
|
Keyboard
|
Mechaical 105 key with Numeric keypad
and built-in touchpad
|
|
Language
|
US (standard), Optional : UK, Chinese
etc
|
|
Color
|
Black
|
|
Protection
|
Anti-glare Tempered
glass
|
|
Auto Power Switch
|
LCD back-light will automatically shut off
when the screen set fold |
|
Security Lock
|
Thumb screw x 2
|
|
Operation Temperature
|
0-50¢X C (32-122¢XF)
|
|
Cable Set
|
15 pin to 15 pin D-sub
cabl, PS2 keyboard & mouse detachable |
|
Display
|
|
Diagonal
|
|
|
Resolution
|
1280 x 1024
|
|
Display Area
|
337.92 x 270.34
|
|
Brightness
|
300
|
|
Contrast Ratio
|
350: 1
|
350: 1
|
400:1
|
|
Viewing Angle
|
160 / 160
|
|
Backlight MTBF
|
50,000 hours
|
|
Number of Color
|
16.2 M
|
|
Input Signal
|
Analog :
0.7Vp-p / 75 Ohms |
|
Frame Rate
|
60Hz(typ), 75Hz (Max)
|
|
KVM Switch |
|
KVM Switch Port
|
N/A
|
8
|
16
|
|
Hot Plug
|
N/A
|
Add PCs or Remove Connected PCs for
Maintenance
without powering down the KVM switch for PCs
|
|
Video Quality
|
N/A
|
Up to 1280 x 1024 with 200 MHz bandwidth
|
|
Auto Scan Mode
|
N/A
|
|
|
|
|
Ordering
information :
|
Part # |
Description |
| LCD1U17-03
Price:$864 |
1U 17" Rack monitor ( TFT
LCD) Keyboard Drawer , 1 cable included |
| LCD1U17-03-8KVM
Price:$1108 |
1U Rackmount 17" TFT LCD
Monitor Keyboard Drawer with 8 port KVM switch, 8 x KVM cables included |
| LCD1U17-03-16KVM
Price:$1448 |
1U Rackmount 17" TFT LCD
Monitor Keyboard Drawer with 16 port KVM switch, 16 x KVM cables
included |
|
|
For more information, please
visit our company web site at
http://www.rackmountmart.com/
Prices and availability subject to change without
notice. Product images may be generic and may not reflect actual
item purchased. Synergy Global Technology Inc is not responsible for any
typographical errors. Specifications subject to change without notice. Legal.
