LCD2U17-05 Short Depth 2U Rackmount 17" Samsung TFT LCD Monitor Keyboard Drawer optional Composite Video / DVI / ARGB/ PS2 /USB connector ( Made in USA )

SHORT DEPTH 2U Rackmount 17" SAMSUNG TFT LCD Monitor Keyboard Drawer
Optional Composite Video + ARGB + DVI Input / Lock / Retainer / USB or PS/2 Interface ( Made in USA ) - Unit depth 13.25" only

LCD2U17-05-d :KB w/ 2 button 16mm trackball and
storage area behind KB

Made in U.S.A.

Features :

-Two rack units high (3.5").
- Attaches directly to a standard VGA card.
- Lock-out ball bearing slides included.
- Wide viewing angle - 160 /160
- 17" SAMSUNG TFT LCD display.
- Five options of keyboard :
a. Keyboard with centered 2 button touchpad
b. Keyboard with illuminated 3 button 1.5" trackball
c. Cherry keyboard with 2 button touchpad
d. Keyboard with 2 button 16mm trackball and storage area
behind keyboard
e. Keyboard with 3 button touchpad and storage area behind
keyboard

Product Sheet

User Manual

LCD2U17-05 with different keyboard options (Click on photos for enlarged views) :

LCD2U17-05-a LCD2U17-05-b LCD2U17-05-cp LCD2U17-05-e

More Photos, click on the following for enlarged view:

Description :

The LCD2U17-05 integrates a choice of 17" SAMSUNG TFT display, keyboard, and pointing device for use in areas where space is a concern. The display does not require special proprietary cards or drivers as it connects directly to a standard VGA connector and automatically switches to the corresponding VGA mode. The unit withdraws from the rack on ball bearing slides which latch in the extended position. The display can then be folded up and the front panel folded down to allow access to the keyboard and mouse for use. When not in use, the display can be folded down which automatically shuts the display power off, and the unit pushed back into the rack and secured by pawl latches.

Specification

Dimensions	19.0" (W) x 3.5" (H) x 13.25" (D) (Rail Depth: 18")
DISPLAY SPECIFICATIONS
Display Type	17" SAMSUNG TFT active matrix LCD.
Resolution	1280 x 1024, 16.7M colors
Brightness	300 cd/m² typical
Contrast Ratio	1000:1 typical
Viewing Angle	Horizontal: 160degrees Vertical: 160degrees
Input Signal	Video: Analog RGB
Video Connector	Signal: 15-pin mini D-sub, detachable
On-Screen Controls	Brightness, Contrast, Position (Vert. & Horiz.), Frequency, Focus, Display Mode
KEYBOARD SPECIFICATIONS
KB Connector	PS/2 or USB
Keyboard types	Type a	KB with centered 2 button touchpad , cannot be used with KVM
	b	KB with illuminated 3 button 1.5" trackball, cannot be used with KVM
	c	Cherry KB with 2 button touchpad, can be used with KVM
	d	KB with 2 button 16mm trackball and storage area behind keyboard, can be used with KVM
	e	KB with 3 button touchpad and storage area behind keyboard, can be used with KVM
Options	Lock , Retainer, S-Video & Composite Video
KVM Compatibility	YES for i. Cherry KB & 2 button touchpad (P/N # LCD2U17-05-c) ii. Keyboard with 2 button 16mm trackball (P/N # LCD2U17-05-d) iii. Keyboard with 3 button touchpad and storage area (P/N # LCD2U17-05-e) *** LCD1U17-05-a and LCD1U17-05-b are Not KVM compatible

Ordering information :

Part #	Description
LCD2U17-05-a-bk Price : $1139	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with centered 2 button touchpad & PS2 connector, black
LCD2U17-05-a-w Price : $1139	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with centered 2 button touchpad & PS2 connector , white
LCD2U17-05-b-bk Price : $1352	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with illuminated 3 button 1.5" trackball & PS2 connector, black
LCD2U17-05-b-w Price : $1352	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with illuminated 3 button 1.5" trackball & PS2 connector, white
LCD2U17-05-cp-bk Price : $1352	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button touchpad & PS2 connector, black
LCD2U17-05-cp-w Price : $1352	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button touchpad & PS2 connector, white
LCD2U17-05-d-bk Price : $1201	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with 2 button 16mm trackball and storage area & PS2 connector, black
LCD2U17-05-f-bk Price : $1366	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button 16mm trackballand storage area & PS2 connector, black
LCD2U17-05-e-bk Price : $1201	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with 3 button touchpad and storage area & PS2 connector, black
LCD2U17-05-a-u-bk Price : $1159	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with centered 2 button touchpad & USB connector , black
LCD2U17-05-a-u-w Price : $1159	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with centered 2 button touchpad & USB connector , white
LCD2U17-05-b-u-bk Price : $1387	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with illuminated 3 button 1.5" trackball & USB connector , black
LCD2U17-05-b-u-w Price : $1387	2U Rack-mount 17" LCD Monitor Keyboard Drawer with illuminated 3 button 1.5" trackball & USB connector , white
LCD2U17-05-cp-u-bk Price : $1372	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button touchpad & USB connector , black
LCD2U17-05-cp-u-w Price : $1372	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button touchpad & USB connector , white
LCD2U17-05-d-u-bk Price : $1236	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with 2 button 16mm trackball and storage area & USB connector , black
LCD2U17-05-f-u-bk Price : $1386	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with Cherry KB & 2 button 16mm trackballand storage area & USB connector, black
LCD2U17-05-e-u-bk Price : $1221	2U Rack-mount 17" SAMSUNG LCD Monitor Keyboard Drawer with 3 button touchpad and storage area & USB connector , black
-M Price : $20	Add Optical Mouse
-R Price : $25	Add retainers
-L Price : $25	Add Lock
-C Price : $25	Add Lock and retainer
-AV Price : $110	Add S-Video &Composite Video inputs + ARGB & DVI inputs
-SBK Price : $150	Add 16” mounting rails

Availability: Usually ships the same business day

LCD2U17-05

$1,139.00

COLOR:
OPTION:
Interface:
Optional Lock / Retainer :
Optional S-Video & Composite video input + ARGB & DVI inputs :
Optional 16inch mounting rails:
