LCDR7U17-05 7U Rackmount 17" SAMSUNG High Contrast Wide viewing Angle TFT LCD Monitor with Optional Lexan /  Composite Video / DVI / ARGB ( Made in USA )



7U Rack Mount 17" SAMSUNG TFT LCD Monitor with Optional Lexan Shield (Made in USA)
*****This model is discontinued .Learn more about replacement model LCDR7U17-09*****







                                       Made in U.S.A.






                                                            *Click on above photos  for enlarged view
                               Free Ground Shipping *Click for details










 A 17" TFT LCD display featuring high contrast and wide viewing angles
while occupying only 1.7" of rack depth
Dimensions 19.0" (W) x 12.25" (H) x 1.7" (D)
Display Type 17"  viewable, Samsung TFT active matrix LCD.
Resolution 1280 x 1024 maximun, 16M colors.
Frequency Horizontal: 31-80 KHz.
Vertical: 55-76 Hz.
Response Time 18 ms (typ).
Brightness 280 nits typical
Contrast Ratio 1000:1 typical
Viewing Angle Horizontal: +89 / -89 degrees
Vertical: +89 / -89 degrees
Input Signal (VGA) Analog RGB, TTL
Video Connector Analog: 15 pin mini HD D-sub.
On-Screen Controls Brightness, Contrast, Position (Vert.  & Horiz.), Auto Adjust, OSD H & V Position
Plug & Play DDC1 and DDC2B
Power AC Input 90-260VAC
Frequency 50/60 Hz
Power Consumption 60 Watts Maximum
Environment Temperature Operating:0 to 50 degrees C
Humidity Operating: 10% to 85% non-condensing

Features :

-17" Samsung Active Matrix TFT LCD display.
- High contrast and wide viewing angle.
- Controls on side of monitor for a clean appearance.
- Optional LEXAN shield.
- Only 1.7" deep allows mounting in confined spaces.
- Plugs directly into a standard VGA card.
- Video and power cables provided


Ordering  information

Part Number  Description
LCDR7U17-05-bk
  7U Rackmount 17" Samsung TFT LCD Monitor , black
LCDR7U17-05-bk-L
  7U Rackmount 17" Samsung TFT LCD Monitor , black with Lexan shield protection on display surface
LCDR7U17-05-lg
  7U Rackmount 17" Samsung TFT LCD Monitor , light gray
LCDR7U17-05-lg-L
  7U Rackmount 17" Samsung TFT LCD Monitor , light gray Lexan shield protection on display surface
-AV  S-Video &Composite Video inputs + ARGB & DVI inputs




LCDR7U17-05
OPTIONS:
Optional S-Video & Composite video input + ARGB & DVI inputs :
