Part # LCD1U17-21-MATRIX ( New design )
** The new design is an improved version.
For comparison between the new and old design, please call. **

General Information Form Factor 1U Rack mounting on slide-out rails Compatibility Multi-platforms - Mix PCs, IBM, SUN, HP , DELL, Linux , Windows                           LCD Screen LCD Type Grade A Industrial monitor 17 inch Active Matrix TFT LCD Panel Display Size 17 inch diagonal Resolutions 1,280 x 1,024 with 60 / 70 / 75Hz  Response time Tr=1.3 / Tf=3.7 ms Contrast ratio 1000 : 1 Brightness 250 cd/ m2 Pixel pitch 0.264 (H) x 0.264 (V) mm Panel color 16.7 million display colors Viewing angle 160° / 160° (Horiz. / Vert.) OSD Control Brightness, Contrast, Phase & Color, H & V position, Auto-tune, Recall & Language Signal Input VGA, Analog RGB Optional Video  Input S-video & Composite (BNC or RCA ), DVI-D      ...More Video Input Details LCD MTBF 50,000 hrs                           Keyboard & Pointing Device Model n Notebook type KB  w/ Numeric Keypad & Touchpad   ...More Keyboard Details                           KVM  ( Keyboard Video Mouse ) Connector                KVM Version DB-15  * DB-15 No KVM  * DB-15 USB KVM   No. of  Console  No of  KVM port 1 ( Local only )   8 or 16 2 ( 1 x local + 1 x remote )   8 or 16 2  ( 1 x local + 1 x IP )   8 or 16  * DB-15 Matrix KVM   No. of  Console  No. of KVM port 2 ( 1 x local + 1 x remote )   8 or 16  3 ( 1 x local + 2 x remote )   8 or 16 3 (1x local +1x remote +1x IP )   8 or 16 4 ( 1 x local + 3 x remote )   8 or 16  4 (1x local +1x remote +2x IP )   8 or 16 4 (1x local +2x remote +1x IP )   8 or 16  CAT6 * CAT6 USB KVM    No. of  Console  No. of  KVM port 1 ( Local only )   8 or 16 or 32 2 ( 1 x local + 1 x remote )   8 or 16 or 32 2  ( 1 x local + 1 x IP )   8 or 16 or 32 * CAT6 Matrix KVM   No. of  Console  No. of KVM port 2 ( 1 x local + 1 x remote )   16 or 32  3 ( 1 x local + 2 x remote )   16 or 32  3 (1x local +1x remote +1x IP )   16 or 32  4 ( 1 x local + 3 x remote )   16 or 32  4 (1x local +1x remote +2x IP )   16 or 32  4 (1x local +2x remote +1x IP )   16 or 32                            Power Supply   -Remote adapter : 110V - 240 V AC Input , 12V 5A Output  -Adapter Size : 4.3"(L) x 2.4"(W) x 1.2"(H) /  10.8 (L) x 6.1 (W) x 3 (H) cm -Cable length from mains plug to adapter :  6ft / 182cm -Cable length from adapter to unit :  6ft / 180cm -Mains plug options available    -Optional  DC power with 48V / 24V / 12V   input power                      Environmental    Temperature  0 to 50 Degree Celsius (Operation)  -25 to 65 Degree Celsius (Storage)  Relative Humidity  90%, non condensing    Shock  50G peak acceleration (11ms, half since wave)     Vibration  58~500Hz/ 0.98G (11min/ cycle)                           Mechanical Product Dimension (W x D x H )   442 x 650 x 44 mm /17.4 x 25.6 x 1.73 inch Product Weight  28 lbs / 12.7kg  Relative Humidity  90%, non condensing                               Regulatory Approval     cUL/UL , FCC , CE , VCCI , 3C*

Front View of 1U LCD   More photos (click to enlarge ) Download Instruction for opening the Rack console  KVM Support    DB-15 KVM DB-15 PS2 kvm Local console DB-15 USB kvm Local console DB-15 USB kvm Local + remote console DB-15 USB kvm Local + IP console    CAT5 / CAT6 KVM Cat5 / Cat6 USB kvm Local console Cat5 / Cat6 USB kvm Local + remote console Cat5 / Cat6  USB kvm Local + IP console    Matrix KVM DB-15 Matrix USB kvm Local + remote console DB-15 Matrix USB kvm Local + IP console Cat5 / Cat6 Matrix USB kvm Local + remote console Cat5 / Cat6 Matrix USB kvm Local + IP console Optional Peripheral & Accessory  - S-Vdieo + Composite Video (BNC or RCA) / DVI-D - DC Power Input ( 12V / 24V / 48V ) - KVM Cables & Cascade Cables in Various Length - USB & PS/2 Dongles - PS2 to SUN /iMac USB adapter         - KVM Extender       -IP KVM Extender  Free Ground Shipping( A $55 Value) *Click for details                                                Customer who ordered this product may also order these : - KVM Switch - Rack Cooling Fan - PDU ( Power Distribution Unit ) - Server Rack Cabinet - Power Strips - 4 Post Rack - Rack Drawer - Wall Rack Mount - Rack Shelves

•  Light weight & New mechanism design - More user friendly on pulling out & opening the unit for operation
•  cUL/UL certified - which will be fit for the projects of UL requirements
•  1U LCD : dual rails rackmount drawer with 17" LCD
•  Multi-user Martrix KVM with either 16 or 32 ports in 1U
•  Direct Support for SUN Micro 1152 x 900 Native Resolution
•  Cost efficient Combo KVM integration
•  Mix PS/2, USB & SUN with Multi-platform switch capability
•  Enchanced aesthetics with new moulded front panel and two point lock
•  All KVM models are interchangeable in the same chassis
•  Multiple keyboard language selections with touchpad
•  104 key notepad keyboard with full numerical pad and SUN hot keys
•  3 button Glidepoint touchpad interchangeable in same chassis
•  Single or "One Man" installation slides for easy, quick installation

Option :

• BNC+S-Video • DVI-D • DC Power • Audio
