Click to enlargeRAG261 - 2U 6-Disk IP RAID storage array

Raid Storage System: Part # RAG261

                                     2U 6-Disk IP RAID storage array
  • Dual iSCSI
  • Disk Support SATA I&II 3Gbps
  • Individual Power & Status Indicator
  • Remote Access & E-mail Notification
    �     �
    �     �
� **Click on pictures to enlarge�
�**Click here to Accessories


� The RAG261 system was built on the world-known hybrid I/O technology, the SATALink , a SCSI-to-SATA converging technology pioneered by Synergy Global Technology to bring low-cost SATA disks to the broadband high performance computing environments. The propriety MultiLink I/O technology is introduced to connect additional disk array system through Multi-lane interface that helped resellers and integrators to offer more cost/effective storage solution to the end customers.
Product Overview

A Pioneer and leader in hybrid I/O technologies, Synergy Global Technology proudly introduces the RAG261 Series, a 2U 6-disk RAID engine embedded intelligent iSCSI rackmount storage system product line, developed for OEM, VAR, & storage solution providers for daily Disk-to-Disk (D2D) backup, video editing, e-mail archive, etc. The RAG261 Series features a next generation 64-bit Scale storage processor capable of sustaining data rates up to 175MB/sec, and offers a cutting edge "web-based" user interface which provides complete storage control over a standard web browser. RAG261 system provides a host of RAID advanced functions, empowering users with capabilities (such as RAID 6 features) normally found in enterprise-class storage systems
Feature & Benefits

  • Hardware RAID Intel 80331 500Mhz 64-bit RISC Processor
  • Host Bandwidth Ultra320 SCSI and backward compatible
  • Disk Supported Serial ATA I&II at 3.0 Gbp/s
  • Built in remote access for event log and e-mail notification
  • RAID levels supported 0, 1, 0+1, 3, 5, 6, 50, 60 & JBOD
  • Support on-line volume expansion & migration
  • Support multiple RAID volumes & instant availability
  • Optional features include RAID 6
Versatile RAID Storage Module

� The RAG261 system is a host independent storage appliance which provides a transparent and driverless method of adding additional RAID protected storage to an existing IT infrastructure, regardless of your operating system or hardware. It is ideal for Microsoft Exchange and SQL server, and provides the fastest, simplest, safest way to share protected data between desktops, networks and work groups.

Next Generation Storage Engine

� Performance Powered by the latest Intel IOP80331 storage processor, the RAG261 system produces an outstanding 175MB/s speed to satisfy for users with video editing, data backup or recovery, and archiving projects.

                                           Technical Specification
� Form Factor � 2U 6-Drive Rackmount
� HDD Interface � SATA / SATA II 3Gb
� RAID Level � RAID 0,1,3,5,6
� Hot Channel � Dual iSCSI
� Number of Disks Supported � Up to 6
� Connectivity � Dual iSCSI Ports
� Performance � Over 175 MB/sec
� Power Supply � Single P250 Watt or
� Redundant 2x460 Watt

Availability: Usually ships the same business day

Upgrade to 460W redundant power supply:
