| EIA RS-310C
19" Rackmount Standard |
|
Construction: |
Heavy Duty Cold Rolled
Electroplated Steel |
|
Color: |
Black or Beige |
|
Motherboard Size: |
Support ATX M/B (Max. to
12"x13" ) |
|
Drive Bays: |
Exposed :1 x 5.25 Slim
CD-ROM + 1 x 3.5 Slim FDD + 24 x Swappable IDE or SATA or SCSI HDD or
Multi-Lan + Internal 2 x 2.5 HDD |
|
Power Supply: |
(Rear Chassis
Installation) 2 sets of 400W or 500W Redundant power supply |
|
Cooling Units: |
3 x 12cm (90 CFM) + 1 x 8cm (42.5 CFM) + 2 x 6cm (23.5 CFM) Heavy Duty Ball Bearing Fans |
|
Expansion Slot: |
2 x USB Ports(Front) |
|
Thermal Management Card: |
Installed |
|
Indicators: |
Leds for Power ON/OFF ,
2xHDD , Fan , Temperature & 3 x LAN Active |
|
Buttons: |
Power ON/OFF , System
Reset , Buzzer Reset |
|
Dimensions: |
483(W) x 222(H) x 650(D)
mm (19 x 8.7 x 25.6) |
|
Product Applications: |
RAID Server, File Server,
Web Server |
|
|
|
