Part # ID-E27Pw
27" High Resolution Widescreen LCD Panel w/ LED-backlit Display
| LCD w/ LED Backlight Panel |
| LCD Type |
LG TFT LCD Panel |
| Backlight |
LED |
| Display Size |
27" Widescreen diagonal |
| Resolutions |
1920 x 1080 |
| Display Color |
16.7 M |
| Brightness |
250 cd/m2 |
| Contrast ratio |
1000 : 1 ( Typical ) |
| Active area (mm) |
598 x 336 |
| Viewing angle |
178° x 178° |
LCD MTBF |
30,000 hrs |
| Signal Input |
HDMI / DVI-D / VGA / S-Video / RCA |
| Power Supply |
Input : Auto-sensing 100 to 240VAC, 50 / 60Hz |
| Consumption :Max. 200 Watt, Standby 20 Watt |
| Mounting |
Universal mount / VESA mount |
| OPTIONS |
| Optional DC Power |
48V / 24V DC Power Details
Input Range:
10~36V(DC-12V, DC-24V model)
36~75V (DC-48V model)
DC power Output : DC 12V
Voltage Accuracy: +/- 1% (Max.)
Safety : Continuous short circuit protection |
Other Option |
- Multi-Display Controller Details
- TV
- MIL-type or lockable connector
|
| Mechanical |
Dimension
( W x D x H ) |
740.9 x 71.5 x 500.4 mm /
29.2 x 2.8 x 19.7 inch |
| Product Weight |
12.7 kgs ( 27.9 lbs ) |
| Environmental |
| Temperature |
0 to 50 Degree Celsius (Operation)
-5 to 60 Degree Celsius (Storage) |
| Relative Humidity |
5 ~ 90%, non condensing |
| Shock |
10G acceleration ( 11 ms duration ) |
| Vibration |
5 ~ 500Hz 1G RMS random vibration |
| Regulatory |
Safety : FCC & CE certified
Environmental : RoHS2 & REACH compliant |
| Package Content |
Package Content |
27” High Resolution Widescreen LCD display X 1, 6ft VGA cable X 1, Power cord X 1, Remote controller X 1
|
|
Front View of ID-E27Pw
Construction
Front / Rear / Top / Side Views & Dimensions
*click on above picture for enlarged view
 Download Product Sheet
Download User Manual
Free Ground Shipping * Click for details
|
|
More Photos, click on the following for enlarged view:
DISPLAY BENEFITS :
- 27" widescreen LCD supports Full HD 1080p resolution
- PIP & Picture by Picture viewing efficiency
- Green LED-backlit panel technology
- Rugged construction against external impact
- Standard with HDMI, DVI-D, VGA, S-Video, RCA, Audio & remote controller
|
 |
0PTIONS :
- 3G / HD / SD-SDI Broadcast-grade input
- MC Multi-display control solution
- Projected Capacitive ( 10-point touch )
- MIL-type or lockable connector
- 48V or 24VDC power
- TV - Analog
|
Diagram for I/O Outlet
Ordering information :
| Part # |
Description |
ID-E27Pw
Price : 759 |
27" High Resolution Widescreen LCD Panel w/ LED-backlit Display, with HDMI, DVI-D, VGA, S-Video, RCA, Audio & remote controller |
| Optional NEMA4 / IP65 |
-N
Price : $122 |
Add NEMA4 / IP65 Protective Glass |
| Optional Video/Audio Inputs |
-SDI
Price: 298 |
Add 3G / HD / SD-SDI Broadcast grade input
(VGA + DVI-D + HDMI + RCA + S-Video + audio + remote controller + SDI) |
Download Spec Sheet |
-MC
Price: 88 |
Add Multi-Display Controller |
Download Spec Sheet |
| Optional Touch Screen |
-TPC
Price : $1186 |
Add Projected Capacitive 10-point multi-touch + USB controller
** casing dimension will be changed if multi-touch is required |
| Optional Controller |
-TV
Price: 136 |
Add TV tuner (NTSC or PAL) with remote controller
(VGA + DVI-D + HDMI + RCA + S-Video + audio + remote controller + TV (analog)) |
| Optional DC power |
-DC24
Price: 420 |
Add 24V DC Power |
-DC48
Price: 420 |
Add 48V DC Power |
-DC110
Price: 644 |
Add 110V DC Power |
-DC125
Price: 644 |
Add 125V DC Power |
| Optional Connectors |
-MD
Price: 88 |
Add MIL-type DC Power lockable jack, male |
Download Spec Sheet |
-MA
Price: 136 |
Add MIL-type VGA lockable jack, male |
Download Spec Sheet |
-LD
Price: 34 |
Add Lockable DC Power jack, male |
Download Spec Sheet |
-LS
Price: 34 |
Add Lockable USB jack |
Download Spec Sheet |
|
|
|
