Click to enlargeLCD1U23-01    23" 4K (UHD)  Wide Screen LCD KVM Drawer , 1U RackMount

Untitled Document

1U Rackmount KVM Tray with Keyboard , Video Monitor and Mouse :
Model # LCD1U23-01


NOVA 1U Rack 23"4K (UHD)Wide Screen LCD KVM Drawer with LED-backlit

Optional DisplayPort KVM , Assembled in USA & TAA Compliant

4K 23" 1U Rack KVM Console LCD1U23-01

*click on image for enlarged view

Features & Benefits Options
  • HDMI 1.4 Video Input
  • 3G / HD / SD-SDI Broadcast-grade input
  • DisplayPort KVM
  • Touch Screen
  • Front USB hub port for device access
  • 250V , 125V , 110V 48V, 24V or 12V DC input

LCD Screen
Display Size 23.8"
Panel Type 4K Ultra High Defination ( UHD)

Resolutions

Native Resolution up to 3840 x 2160

Viewing Angle

89/89/89/89

Contrast Ratio

1000 : 1

Brightness

310 cd/m2

MTBF (hrs)

30,000

Colors 1.07 Billion, 10-bit

Response Time :

25 ms

Dot Pitch :

0.13725 mm

Display Area:

527.04 H x 296.46 V

Surface Treatment :

Anti-glare

Surface hardness:

3H

Back Light

LED

Console Port
Video Input Displayport 1.2
KB / MS USB type B
DisplayPort console cable : Part Number : LCD-A3007-6 , 6-ft long
Drawer end : Displayport + USB type B (KB/MS)
Server end : Displayport + USB type A
Video OPTION
HDMI ( Digital) HDMI 1.4 / HDCP 1.4
SDI 3G / HD / SD-SDI
Audio OPTION
Input Connector : 3.5mm stereo jack
Impedance /Power Level : 30k ohms/ 750mV
Output Connector : 3.5mm stereo jack
Resistance /Power Level : 30k ohms/ 2.8V
Speaker Dual Stereo : 2W x 2
Keyboard & Pointing Device

Model n / b

Standard Windows Keyboard with/ Numeric Keypad & Touchpad OR Trackball

Model Mn / Mb
(MAC)

Optional MAC Keyboard and Hot-Keys with Numeric Keypad & Touchpad or Trackball

Model Sn / Sb
(SUN)

Optional SUN Keyboard and Hot-Keys with Numeric Keypad & Touchpad or Trackball

Power Supply
Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Consumption
(Single Console)
Screen On : Max. 45W
Power saving mode : Max. 9W
Power button On : Max. 2W
Consumption
(Mulitport KVM Console)
Screen On : Max. 54W
Power saving mode : Max. 18W
Environmental
Temperature 0 to 55 Degree Celsius (Operation)
-20 to 60 Degree Celsius (Storage)
Relative Humidity 20~90%, non condensing (Operation)
5~90%, non condensing (Storage)
Altitude 16,000 ft (Operating)
40,000 ftn(Non-Operating)
Shock 10G acceleration(11ms duration)
Vibration 10~300Hz 0.5G RMS random vibration
Mechanical
Product Dimension Single Port KVM Console :
442(W) x 650(D) x 44(H) mm /
17.4(W) x 25.6(D) x 1.73(H)inch
Multi Port KVM Console :
442(W) x 750(D) x 44(H) mm /
17.4(W) x 29.5(D) x 1.73(H) inch
Product Weight Single Port KVM Console : 33.7lbs / 15.3kgs
Multi Port KVM Console: 35.4lbs /16.1kgs
Mounting Range
Single Port KVM Console :
660mm ~ 890mm / 26 inch ~ 35 inch
Multi Port KVM Console :
660mm ~ 970mm / 26inch ~ 38.2 inch
Regulatory Approval
FCC, CE, CE/LVD , RoHS2 Compliant , REACH Compliant , Assembled in USA , TAA Compliant

Download User Manual





Optional Peripheral & Accessory
- DC Power Input ( 12V / 24V / 48V / 110V / 125V / 250V )
Customer who ordered this product may also order these :
- Server Rack Cabinet
- Wall Mount Rack
- KVM Switch
- Rack Mount Keyboard
- 2 Post / 4 Post Steel Rack - Rack Shelf
- Rack Light
- 2 Post / 4 Post Aluminum Rack - Intellignet Rack Cabinet Door Lock Handle
- PDU / Power Distribution Unit - Remote / Network Control for Rack Cabinet Access
- Rack / Cabinet / Wall Mount Cooling Fans - Data Center Environmental Monitoring

ORDERING INFORMATION FORNOVA LCD1U23-01:
1U RACKMOUNT KVM CONSOLE WITH 23.8" 4K (UHD) INDUSTRIAL GRADE LCD PANEL

Displayport KVM : 1 Active User
Local Console & Optional Remote Console ( Via CAT6 or Over IP)
LOCAL CONSOLE ONLY
No. of Console /
KVM Choice
No. of
KVM port
KVM Cable Keyboard Part Number Price
1 Local Console / Single Port KVM 1
1 x DisplayPort Console cable
Part# LCD-A3007-6
Touchpad LCD1U23-01-n $1,439
Trackball LCD1U23-01-b
1 Local Console / MulitPort KVM 12 Touchpad LCD1U23-01-12DKVM-n Please call
Trackball LCD1U23-01-12DKVM-b
LOCAL CONSOLE + REMOTE CONSOLE ( Via CAT6 or Over IP )
No. of Console /
KVM Choice
No. of
KVM port
KVM Cable Keyboard Part Number Price
1 Local Console + 1 Remote Console (Via CAT6 ) /
MultiPort KVM
12
Touchpad LCD1U23-01-12DKVM2-n Please call
Trackball LCD1U23-01-12DKVM2-b
1 Local Console + 1 Remote Console (Over IP) /
MultiPort KVM
12 Touchpad LCD1U23-01-12DKVM2IP-n Please call
Trackball LCD1U23-01-12DKVM2IP-b
Optional Right Side Opening
-R
Price : Free
Change Opening from Left Side to Right Side
Optional Keyboard & Pointing Devices
-Mn
Price : $192
Change Standard Windows Keyboard to MAC keyboard with touchpad
-Mb
Price : $192
Change Standard Windows Keyboard to MAC keyboard with trackball
-Sn
Price : $192
Change Standard Windows Keyboard to SUN keyboard with touchpad
-Sb
Price : $192
Change Standard Windows Keyboard to SUN keyboard with trackball
Optional Video /Audio Inputs
-SDI
Price : $314
3G / HD / SD-SDI Broadcast grade input with speaker AND Displayport
-HDMI
Price : $114
HDMI 1.4 with speaker , No Displayport
Optional Front USB Port
-USB
Price : $114
Add Front USB Port ( Available for Single Console ONLY )
Optional DC Power
-DC12
Price : $343
Add 12V DC power supply   DC sheet
-DC24
Price : $343
Add 24V DC power supply   DC sheet
-DC48
Price : $343
Add 48V DC power supply   DC sheet
-DC110
Price : $414
Add 110V DC power supply
-DC125
Price : $414
Add 125V DC power supply
-DC250
Call for price
Add 250V DC power supply




Availability: Usually ships the same business day

LCD1U23-01$1,439.00


MODEL Single Port Combo KVM:

Optional Right Side Opening:

Optional Keyboard & Pointing Device:

Optional Video/Audio Inputs :

Optional Front USB Port :

DC Input Power Option :
