Click to enlarge LCDR3U04-01-Quad 3U Rack Mount Quad 4 x 4" Color TFT LCD Monitors





                                                3U Rack mount  Quad 4 x 4" Color TFT  LCD Monitors
            Free Ground Shipping *Click for details


Features :
-  Quad 4 x 4" TFT LCD panel
- Rotate Angle:Up Down:24°
- Viewing angle -  Horizontal : ±45°  -Vertical : +30°/-60°
- Fits in standard 19" rack/cabinet
- On Screen Display (OSD)

  More photos (click to enlarge )


Dimensions 483mm (W) x 78mm (H) x 132mm (D)
Color Black
Display Type 4"  Color TFT x 4
Resolution 480 (W) × 234 (H)
Pixel Pitch(mm) 0.171 (W) × 0.264 (H)
Rotate Angle Up Down: 24°
Brightness 250 nit
Contrast Ratio 150:1
Viewing Angle Horizontal: ±45°
Vertical: +30°/-60°
Input Video System 1.0Vp -p@75ohm (Auto Switch)
NTSC: ƒH: 15.75Khz PA L: ƒH: 15.625Khz
ƒV: 60Hz ƒV: 50Hz
Input/Output Connector BNC×4
OSD Function Video Left -Right Reverse Switch
Bright ness & Contrast Hot Key direct access
Output Video System 1.0Vp -p@75ohm
Power AC Input AC110V ~ AC220V
Frequency 50/60 Hz
Power Consumption 20 Watts Maximum
Environment Temperature Operating: 0°C ~60°C
Storage: 0°C ~80°C

Ordering  information

Part Number  Description
LCDR3U04-01-Quad
 3U Rackmount Quad 4" TFT LCD Monitor , black




LCDR3U04-01-Quad
