1U 19” Keyboard Sliding Shelf
Part # RA7046
|
 Dimension Drawing |
| Specification |
1U 19” Solid plate
Plate depth: 12”
Made of 18-Gauge Steel
Loading capacity : 50 lbs
Finish and Color : Black
RA7046:
Unit Depth (effective) WxDxH: 16.25" x 11.75" x 1.75"/ 412.75 x 298.45 x 44.45mm
Unit Depth (overall) WxDxH: 19" x 12" x 1.75"/ 482.6 x 304.8 x 44.45mm
Support Depth: 11.5”~16” (292.1~406.4mm)
** Height of Mounting bracket : 2" / 50.8mm
RA7046-LBK:
Unit Depth (effective) WxDxH: 16.25" x 11.75" x 1.75"/ 412.75 x 298.45 x 44.45mm
Unit Depth (overall) WxDxH: 19" x 12" x 1.75" / 482.6 x 304.8 x 44.45mm
Support Depth: 27.38”~32.38”(695.33~822.33mm)
** Height of Mounting bracket : 2" / 50.8mm
|
|
