 RM4023  4U Military Grade Rackmount Chassis3x 5.25" Open Bay + 10x 3.5" Swappable HDD Tray/Carrier optional power supply

Untitled Document



Click on images for enlarged views.




19" Rackmount Standard
Mounting: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard) , Beige or Custom
System Board Size: Supports EATX M/B (Max. to 12" x 13") (Standad) OR
14/15-slot Passive Backplane ( SR Version)
Drive Capacity: 3 x CD-ROM & 10 x 3.5" Hot-Swappable SATA / SCSI / SAS Trays
Power Supply: Optional PS/2 Size Single up to 700W or Mini Redundant up to 500W ATX P/S (Rear Installation) Max. Depth 300mm
Cooling Units:

3x (120mm = 90CFM each) Fans & 2 x (60mm = 23.5CFM each)(Optional) Fans

Expansion Slot : 7 Slots or 14/15 Slots (SR Version)
Connector Port : 2 x USB Ports (Front)
Front Door: Single Door with 2 Thumbscrews
Button: Power ON/OFF Momentary (Dimple), System Reset
Dimensions: 19" x 7.0" x 24.5" (483 x 177 x 624 mm) (W x H x D)
Humidity: 5% - 95% Non-condensing
Compliance : RoHS Compliant , TAA Compliant
Download Mechanical Drawing

For more pictures , click on the following for enlarged view:






Availability: Usually ships the next business day

RM4023$647.00
Model:
Optional 14/15-Slot Back Panel:
Optional Power Supply:
