| 19" Rackmount Standard |
| Mounting: |
19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| System Board Size: |
Supports EATX M/B (Max. to 12" x 13")(Standard) OR
14/15-Slot Passive Backplane |
| Drive Capacity: |
1x 3.5" FDD & 2x 3.5" HDD & 1x Slim CD-ROM |
| Power Supply: |
Optional PS/2 Size Single up to 700W or Mini Redundant up to 500W ATX P/S (Rear Installation) Max. Depth 230mm |
| Cooling Units: |
2x (92mm = 51CFM each) &
2x (60mm = 23.5CFM each) Fans (Optional) |
| Expansion Slot : |
7 Slots or 14/15 Slots (SR Version) |
| Connector Port : |
2 x USB Ports(Front) |
| Air Filter: |
Inside Front Panel (Washable) |
| Switch: |
Power ON/OFF, System Reset |
| Dimensions: |
19" x 7" x 17.6" , ( 483 x 177x 447mm ) (W x H x D) |
| Humidity: |
5% - 95% Non-condensing |
| Compliance : |
RoHS Compliant, TAA Compliant |
Mechanical Drawing
 |
