*click to enlarge |
Features :
-17" SAMSUNG
TFT LCD panel with resolution 1280 x 1024
- High contrast ratio 500: 1 for excellent picture quality
- Viewing angle - Horizontal : 150 degrees -Vertical (U/D) :
135 degrees
- Space saving : only 2.5" deep, enable mounting in confined
spaces
- Fits in standard 19"
rack/cabinet
- Steel front panel construction with a durable powder coat finish
- Analog & Digital Inputs
- On Screen Display (OSD)
|
|
|
|
|
|
Dimensions |
19.0" (W) x 12.25" (H) x 2.5" (D)
|
|
Color |
Black |
|
Display Type |
17" SAMSUNG TFT active matrix LCD. |
|
Resolution |
VGA up to 1280 x 1024 maximum, 16.2 M
colors.
|
|
Frequency |
Horizontal: 30-81KHz
Vertical: 56-75Hz |
|
Response Time |
< 12 ms (typ). |
|
Brightness |
270 nits typical |
|
Contrast Ratio |
500:1 typical |
|
Viewing Angle |
Horizontal: 150 degrees
Vertical: 135 degrees |
|
Input Signal |
VGA: RGB. Analog Video, TTL H & V sync
Digital : DVI-D (TDMS) |
|
Input Connector |
Analog : 15-pin mini D-sub Digital
: 24 pin DVI-D |
|
On-Screen Controls |
Brightness, Contrast, Position (Vert.
& Horiz.), Auto Adjust, OSD H & V Position, Input Select , Reset,
Color Temp |
|
Plug & Play |
DDC1 and DDC2B |
|
Power |
AC Input |
100-240VAC |
|
Frequency |
50/60 Hz |
|
Power Consumption |
38 Watts Maximum |
|
Environment |
Temperature |
Operating:10 to 40 degrees C
Storage: -20 to 45 degrees C |
|
Humidity |
Operating: 10% to 80% RH (max) |
|
|
Ordering information
|
Part Number |
Description |
|
LCDR7U17-07 |
7U
Rackmount 17" SAMSUNG TFT LCD Monitor , black |
|
|
