 RM3012 3U Rackmount Chassis 2 x 3.5" Hot-Swap SATA tray + 1 x 5.25" or (1 x Slim ODD + 3.5") Open, 1 x 3.5" Internal HDD optional Power supply

   EIA RS-310C 19" Rackmount Standard


Heavy Duty Cold Rolled Electroplated Steel



System Boards:

Pentium 4, Pentium D, Dual Xeon, AMD 64, Dual Opteron

Motherboard Size:

Support EATX M/B (Max. to 12" x 10") SSI EEB 3.0

Drive Bays:

(Option A): 1x 5.25" CD-ROM & 1x 3.5"FDD & 2 x 3.5"Swappable Trays (Option B): 1x 5.25" Slim CD-ROM & 2x 3.5"FDD & 2x 3.5"Swappable Trays

Power Supply:

2U Single or Redundant up to 400W ATX P/S (Rear Installation) Max. Depth 300mm

Cooling Units:

1 x (80mm), (2 x (60mm), and (2 x 40mm) (Optional)

Expansion Slot:

7 x Vertical Full Height PCI Slots

Connector Port (front): 2x USB


LEDs for Power, HDD Activity, & LAN


Power ON/OFF Momentary (Rocker), System Reset


(W x H x D):

483 x 133 x 400mm (19" x 5.2 " x 15.7")


5% - 95% Non-condensing

Product Applications:

Multipurpose Server

            Download Dimensional Drawing
  More photos (click to enlarge )

Availability: Usually ships the next business day

Open Bay Options:
