TAC502 - a portable desktop RAID storage system with X-type handle for up to five (5) SATA disks. TAC502 is popular among advanced gamers & desktop publishing

Raid Storage System: Part # TAC502

The TAC502 is a portable desktop RAID storage system with X-type handle for up to five (5) SATA disks. TAC502 is popular among advanced gamers & desktop publishing.

  • On-line Volume Expansion
  • Up to SATA I/II Hard Disks
  • Remote Access & Email Notification
  • Excellent Venting and Cooling System
    �     �
    �     �
� **Click on pictures to enlarge�
�**Click here to Accessories


� The TAC502 system was built on the world-known hybrid I/O technology, the SATALink�, a SCSI-to-SATA converging technology pioneered by Synergy Global Technology to bring low-cost SATA disks to the broadband high performance computing environments. The SATALink� hybrid I/O technology has been since helped resellers and integrators to offer more cost/effective storage solution to the end customers.

Product Overview

   Proudly presented by Synergy Global Technology, the TAC502 is a small form factor desktop storage system with built-in RAID Engine that targets DV savvy, enthusiastic gamer, and IT manager. It is a pre-configured RAID storage system that wraps five (5) Serial ATA (I, II) disks into one RAID (0, 1, 3, 5 & 6) protected disk, while connecting to the high speed Ultra320 SCSI port. With email notification and remote access built-in, the TAC502 is ideal for Microsoft Exchange and SQL server, and provides the fastest, simplest, safest way to share protected data between desktops, networks and work groups. There are three styles of TAC502 system available for OEM, SI, and VAR to choose from that best suit for their application environment.
Ideal Applications

  • For JBOD or RAID
  • Data Protection or Disk-to-Disk Backup
  • Digital Video Recording (DVR) or Surveillance
  • Video Editing (DV, SD, HD)
  • Digital Audio Recording
  • Desktop Publishing

� Powered by the latest Intel storage processor, the TAC502 produces an outstanding 240MB/s speed to satisfy for users with large video editing, data backup or recovery, and archiving projects.

Appliance-based Storage

� TAC502 is a host independent storage appliance which provides a transparent and driverless method of adding additional RAID protected storage to an existing IT infrastructure, regardless of your operating system or hardware. With built-in hardware RAID 5 engine and robust functionality and flexibility, TAC502 system truly offers a flexible and powerful solution that will increase your capacity, productivity and add unprecedented data protection, that were found only in the high end storage system.

Easy Management

� TAC502 system is unparalleled in its simplicity, easy of use, installation, and storage management. Our user friendly Web Graphical User Interface allows one to deploy and manage the disk array from virtually anywhere in the world with simple internet access, no additional management software ever needed. With the "Quick Install" wizard, the storage administrator can get the system up and running in a few minutes; and setting up RAID level, volume, cache, etc. can all be done and monitored through the Web GUI.

                                           Technical Specification
� Form Factor � Desktop 5-Drive Tower
� HDD Interface � SATA / SATA II 3Gb
� Enclosure Material � Metal in Black Color
� Hot Channel � 1 x U320 / HD68-pin
� Number of Disks Supported � Up to 5
� Network Management � Yes via RJ45
� Terminal Management � Yes via RS232
� Additional Device Option � 1 x 5.25" Opening
� Performance � Over 240 MB/sec
� Power Supply � Single 250 Watt

Availability: Usually ships the same business day
